Product introduction
The pulp-containing juice filling machine is an integrated automatic filling equipment specially developed for granular and pulp-containing beverages. It integrates multiple functions including bottle rinsing, quantitative pulp filling, juice refilling and capping and sealing, breaking through the technical bottleneck that ordinary filling machines cannot adapt to pulp and granular materials. Adopting a dual-channel layered filling process, the equipment can accurately separate and proportion juice and pulp, effectively solving industry problems such as pulp precipitation, blockage, uneven filling and particle breakage. It supports multiple production processes including hot filling and medium-temperature filling, serving as the core special equipment for fruit and vegetable juice and pulp beverage production lines.
product Parameter(specification)
The core data details of the equipment are as follows:
|
Material Parameters |
High-rigidity support structure, food-grade stainless steel + special surface treatment for other parts; |
|
Packaging Size Parameters |
Optional box bottom sizes 57×57mm, 70×70mm, 83×83mm, 95×95mm, only one specification for single batch production; |
|
Capacity Data |
3000 boxes per hour; |
|
Filling Volume Data |
250-500ml (57×57mm), 500-1000ml (70×70mm), 1000-1500ml (83×83mm), 1500-2000ml (95×95mm); |
|
Lid Parameters |
Compatible with 26-36mm lids, dual capping/non-capping modes, single mode operation per batch; |
|
Filling Temperature Parameters |
Room temperature (no temperature control required); |
|
Power Parameters |
Total power 25KW, three-phase power supply system; |
|
Shelf Life Parameters |
No fixed value, determined by product type and production process; |
|
Air Pressure Parameters |
Compressed air pressure 1.0-1.4Mpa, flow 1.4-2m³/min, oil-free and dust-free; |
|
Water Cooling Parameters |
Cooling water flow ≥40L/min, constant water temperature 30℃; |
|
Appearance Parameters |
Length 4m, Width 1.4m, Height 2.8m; |
|
Weight Parameters |
Total weight 3500KG; |
|
Installation Parameters |
Compatible with cement, tile and plastic floors, no corner plastering required; |
|
Functional Parameters |
Built-in filling enhancement function to eliminate liquid foaming and splashing during filling. |
product feature and application
It is suitable for various pulp juices such as mango, orange, aloe, coconut and pineapple, compatible with multiple packaging containers including PET bottles, glass bottles and metal cans. It supports normal-temperature, medium-temperature and high-temperature filling modes to meet the anti-corrosion and production process requirements of different beverages.This equipment is widely used in the food and beverage processing industry for the production of various beverages containing pulp, particles and fibers
product details
From the processing of raw roof box paper sheets to the completion of finished products, the whole process including bottom pre-shaping, bottom temperature rising and heating, bottom sealing shaping, ultrasonic fitting and film covering, top pre-forming, material filling and feeding, top sealing forming, date printing and marking, and finished product packaging and sealing is required. All production steps are fully automatically executed and fully controllable by the computer system, and stable production can be realized only with single-person on-duty supervision.
product qualification
This pulp-containing juice filling machine specifically solves the core problems of pulp filling in the industry. Different from ordinary liquid filling machines, its exclusive layered split-flow filling technology fundamentally avoids common problems such as fruit grain breakage, uneven filling, pipeline blockage and sedimentation. Certified by food-grade safety standards, the machine operates stably with precise metering, with the mass production filling error controlled within ±1% and the pulp integrity rate reaching more than 98%.
Deliver, shipping and serving
We can help you predict future market trends and analyze your corporate profits. We will arrange personnel to visit and inspect related enterprises on your behalf. We offer all kinds of training with both theoretical knowledge and practical skills. We provide free on-site installation and debugging for equipment, and overseas services will follow the rules agreed by both sides. We can arrive on-site within 48 hours for after-sales service. All our equipment has a one-year full warranty and we will serve you for life. We will keep sending you the latest industry technology information and market news. We also provide follow-up services when you need to update or improve your equipment.
FAQ
Q1: How can I obtain detailed equipment specifications and pricing?
A1: You may obtain detailed specifications and quotes through the following methods:
① Visit our official website (www.sybeiya.com) and check the detailed parameters of the gable top carton filling machine in the Product Center section, or submit an online inquiry;
② Directly call our sales hotline (+8613840309495) to discuss your requirements with a sales consultant and receive a precise quotation;
③ Bring your product samples and requirement specifications to our factory for an on-site visit. We will arrange for professionals to provide detailed product introductions and quotation proposals.
Q2: In one machine can fill for different volume?
A2:The equipment supports multiple gable-top packaging specifications, accommodating filling capacities of 200ml, 330ml, 380ml, 500ml, 750ml, 1000ml, and 2000ml. Note that each machine supports only one box base size, but the box height is flexibly adjustable. By adjusting the height, it can fill beverages of different capacities, achieving multi-capacity compatibility. Additionally, the equipment supports composite packaging materials made from different materials (e.g., paper-aluminum-plastic composite, plastic-plastic composite, etc.), and can be customized and debugged to match the packaging requirements of the customer's products.
It is also compatible with packaging materials and lids from various global manufacturers, ensuring complete compatibility.
