Product introduction
The coffee filling equipment is a customized automatic filling and packaging machine for coffee products. It is suitable for various forms of coffee such as instant coffee powder, ground black coffee, liquid coffee and cold brew coffee. It can automatically complete integrated processes including quantitative filling, sealing, nitrogen flushing preservation and labeling. Adopting food-grade materials and intelligent control systems, the equipment balances filling accuracy, production efficiency and food hygiene standards. Widely applied in coffee food processing factories, it supports multiple packaging specifications serving as the core automatic equipment for large-scale and standardized coffee production.
product Parameter(specification)
The core data details of the equipment are as follows:
|
1. Material Parameters |
High-rigidity support structure, food-grade stainless steel + special surface treatment for other parts; |
|
2. Packaging Size Parameters |
Optional box bottom sizes 57×57mm, 70×70mm, 83×83mm, 95×95mm, only one specification for single batch production; |
|
3. Capacity Data |
3000 boxes per hour; |
|
4. Filling Volume Data |
250-500ml (57×57mm), 500-1000ml (70×70mm), 1000-1500ml (83×83mm), 1500-2000ml (95×95mm); |
|
5. Lid Parameters |
Compatible with 26-36mm lids, dual capping/non-capping modes, single mode operation per batch; |
|
6. Filling Temperature Parameters |
Room temperature (no temperature control required); |
|
7. Power Parameters |
Total power 25KW, three-phase power supply system; |
|
8. Shelf Life Parameters |
No fixed value, determined by product type and production process; |
|
9. Air Pressure Parameters |
Compressed air pressure 1.0-1.4Mpa, flow 1.4-2m³/min, oil-free and dust-free; |
|
10. Water Cooling Parameters |
Cooling water flow ≥40L/min, constant water temperature 30℃; |
|
11. Appearance Parameters |
Length 4m, Width 1.4m, Height 2.8m; |
|
12. Weight Parameters |
Total weight 3500KG; |
|
13. Installation Parameters |
Compatible with cement, tile and plastic floors, no corner plastering required; |
|
14. Functional Parameters |
Built-in filling enhancement function to eliminate liquid foaming and splashing during filling. |
product feature and application
This equipment is widely applied to the whole range of coffee production and processing scenarios, including the quantitative filling and sealing of instant pure coffee powder, 3-in-1 coffee powder, drip coffee, roasted ground coffee, concentrated coffee liquid and cold brew ready-to-drink coffee.
product details
Standardized full-link production of roof boxes: paper sheet base bottom pre-forming, bottom heating treatment and curing, bottom sealing forming and closing, ultrasonic film covering and processing, top pre-shaping and forming, internal quantitative material filling, top sealing forming and shaping, product production date printing and marking, and finished product packaging and factory delivery. The whole production process realizes programmed full-automatic operation with precise computer regulation, and only one staff member is required for on-duty and simple operation maintenance throughout the process.
product qualification
This coffee filling equipment strictly complies with national food machinery safety standards and food production hygiene specifications. The whole machine is manufactured with compliant food-grade raw materials, and core metering, control and sealing components adopt high-quality industry brand accessories, ensuring stable operation, accurate metering and qualified hygiene standards.
Deliver, shipping and serving
We integrate business consulting, enterprise service, technical training, equipment engineering and after-sales guarantee to create a full-link service system for clients. Our business consulting items include precise market forecasting and professional profit benefit analysis. Our enterprise service covers standardized field visit and inspection organization. Our training service integrates systematic theoretical teaching and practical skill guidance. Our equipment on-site service provides free installation and commissioning, with overseas service implementation following bilateral contractual provisions. We adopt a 48-hour ultra-fast on-site response mode, and provide one-year full machine warranty and lifelong all-round service for all equipment. In addition, we realize real-time update of industry technical intelligence and provide exclusive follow-up upgrade services for equipment technical improvement and function optimization.
FAQ
Q: What after-sales services does your company provide after purchasing the equipment?
A: We provide comprehensive after-sales service guarantees:
①Free on-site installation and commissioning (for domestic customers). For international customers requiring on-site installation, the buyer shall cover round-trip airfare, accommodation, visa fees for our technicians, plus a daily service fee of $150 USD.
②Professional operator training to ensure staff master equipment operation and basic maintenance.
③One-year equipment warranty covering free replacement of non-human-damaged parts and complimentary repairs;
④24/7 service hotline for prompt maintenance requests, with on-site technicians arriving within 24 hours for nearby areas and 48 hours for remote regions;
⑤Long-term supply of wear-and-tear parts to ensure sustained equipment stability.
