Product introduction
The carton water packaging machine is a fully automatic integrated packaging equipment specially designed for carton-packed drinking water and beverages. It integrates carton forming, material filling, sealing, cutting and conveying. Adopting PLC intelligent control system and servo precise transmission structure, the equipment realizes automatic continuous operation and adapts to various specifications of carton beverage packaging. It is widely applied in beverage production lines and serves as the core equipment for standardized and efficient packaging in the beverage industry.
product Parameter(specification)
|
Basic Hardware Parameters Material: Food-grade stainless steel for non-support parts with special surface treatment; Size: 4m×1.4m×2.8m; Weight: 3500KG; Power: 25KW (three-phase power supply); Installation: Compatible with cement/tile/plastic floors, no corner plastering required |
Supporting Working Condition Parameters Compressed Air: Pressure 1.0-1.4Mpa, flow 1.4-2m³/min, oil-free and dust-free; Cooling Water: Flow ≥40L/min, water temperature 30℃; Shelf Life: Determined by product type and production process |
|
Production Specification Parameters Capacity: 3000 boxes per hour; Box Specifications: 57×57mm, 70×70mm, 83×83mm, 95×95mm (single selection); Filling Volume: 250-500ml, 500-1000ml, 1000-1500ml, 1500-2000ml; Lid Size: 26-36mm, switchable single capping/non-capping mode; Filling Temperature: Room temperature |
Core Equipment Advantages Equipped with exclusive filling enhancement function to effectively inhibit liquid foaming and splashing during filling, stabilize production effect and reduce material loss |
product feature and application
This equipment is mainly used for the automatic carton packaging production of liquid foods such as drinking water, boxed beverages, functional drinks and normal-temperature beverages. It is widely applicable to production scenarios including small and medium-sized beverage processing factories, large-scale beverage production enterprises and food processing industrial parks. It can not only connect with fully automatic mass production lines, but also adapt to the flexible, small-batch and multi-specification production mode of small and medium-sized enterprises, covering various commercial beverage packaging scenarios.
product details
Whole steps of roof box sheet forming production: bottom pre-forming process treatment, bottom heating curing treatment, bottom sealing and forming, ultrasonic surface covering processing, top pre-shaping and forming, material filling and supply, top sealing and shaping, product production date printing, and finished product packaging and delivery. All production steps realize computer automatic control with stable and controllable whole process, and only one staff member is required for supervision.
product qualification
This carton water packaging machine strictly complies with the production standards of the food machinery industry and has passed multiple quality and safety system certifications with stable overall performance and mature technology. Verified by extensive market application, it has served hundreds of beverage production enterprises nationwide and adapts to various production working conditions.
Deliver, shipping and serving
As a professional service provider, we offer comprehensive value-added services for all cooperative clients. We assist enterprises in market trend prediction and financial profit analysis to enhance market competitiveness. We organize standardized field visits and operational inspections for partner enterprises to standardize daily management. High-quality training integrating theory and practice is provided to improve staff professional skills. Free on-site equipment installation and commissioning services are available, with overseas service terms subject to bilateral negotiation agreements. A 48-hour efficient on-site service mechanism ensures rapid problem resolution. All equipment is covered by one-year full machine warranty and lifelong exclusive after-sales service. We continuously deliver frontier industry technology and market intelligence. Meanwhile, we provide long-term follow-up technical support for equipment upgrading and iterative improvement.
FAQ
Q1: How can I obtain detailed equipment specifications and pricing?
A1: You may obtain detailed specifications and quotes through the following methods:
① Visit our official website (www.sybeiya.com) and check the detailed parameters of the gable top carton filling machine in the Product Center section, or submit an online inquiry;
② Directly call our sales hotline (+8613840309495) to discuss your requirements with a sales consultant and receive a precise quotation;
③ Bring your product samples and requirement specifications to our factory for an on-site visit. We will arrange for professionals to provide detailed product introductions and quotation proposals.
Q2: What are the differences between gable top carton and Tetra Pak?
A2: Gable top carton uses sheet-based packaging material. A single machine can fill multiple capacities, which are adjustable. Production speeds range from low to high, accommodating various types of contents.
Tetra Pak uses roll-based packaging material. A single machine can only fill one fixed capacity, which is non-adjustable. These machines lack low-output options, are expensive, and incur high maintenance costs.
