Product introduction
The red wine filling machine is an automated filling equipment specially designed for non-carbonated wines such as red wine and fruit wine. Adopting the core micro-negative pressure filling technology, it is applicable to the quantitative filling operation of glass bottles of various specifications. Integrated with rinsing, filling and capping functions, the equipment realizes full-automatic operation, effectively avoiding problems such as red wine oxidation, foaming and overflowing. It accurately controls the filling liquid level and maximally retains the original taste and quality of red wine, serving as the core supporting equipment for small and medium-sized wineries and large-scale wine production.
product Parameter(specification)
The biggest technical highlight of this automatic filling equipment is the customized filling enhancement system, which targets the common industry problems of liquid foaming and splashing during filling, greatly improving filling accuracy and production cleanliness. The equipment adopts high-standard hardware configuration. To adapt to clean production scenarios, all functional components except the high-rigidity load-bearing support structure are made of food-grade stainless steel with refined special surface treatment, featuring rust resistance, corrosion resistance and easy cleaning. The equipment has stable production performance, completing 3000 standardized filling boxes per hour. It has flexible packaging adaptability with four mainstream box sizes (57×57mm, 70×70mm, 83×83mm, 95×95mm). Only one specification can be selected during production, and parallel production of multiple specifications is not supported. Each box size corresponds to an accurate gradient filling capacity, fully covering small, medium and large volume needs: 250-500ml, 500-1000ml, 1000-1500ml, 1500-2000ml. The equipment supports dual-mode production, realizing capped sealed production and uncapped open production for 26-36mm lids, with multi-function and single production mode for each operation. The whole filling process adopts room-temperature technology without temperature control auxiliary equipment, saving energy and reducing consumption.
The power configuration is 25KW three-phase power supply, complying with industrial power consumption standards. The product shelf life has no fixed value, which is completely determined by material characteristics and production technology. The supporting power medium parameters are accurately controllable: the compressed air pressure is 1.0-1.4Mpa with a flow rate of 1.4-2m³/min, maintaining oil-free and dust-free cleanliness; the cooling water flow is no less than 40L/min with a constant temperature of 30℃. The overall equipment size is 4m×1.4m×2.8m with a total weight of 3500KG, featuring regular layout and reasonable floor space. It has a wide range of installation scenarios, suitable for all conventional industrial floors without additional corner plastering procedures.
product feature and application
Wide adaptability and strong practicality. It is suitable for different specifications from 250ml to 2000ml, compatible with various wines such as dry red wine, sweet red wine and fruit wine. With a compact structure, small footprint, easy installation and maintenance, it adapts to production lines of different capacities.This equipment is widely used in large, medium and small wineries, red wine processing factories and wine food production enterprises, mainly for the large-scale filling production of wines such as dry red wine, sweet red wine, low-alcohol fruit wine and homemade red wine.
product details
High-precision roof box production process: raw paper sheet bottom pre-processing and shaping, bottom thermal shaping treatment, bottom sealing and forming, high-precision ultrasonic covering, top pre-forming shaping, precise material filling, bottom sealing shaping, laser date printing, and standardized finished product sealing. The whole production line is regulated by computer intelligent programs throughout the whole process with high automation, and a single person can independently complete full-line production management.
product qualification
Strong after-sales adaptability: The equipment supports customized debugging, and parameters can be adjusted according to customers' bottle types, production capacity and wine characteristics. It features simple installation and debugging, convenient later maintenance and full-process technical support to ensure stable operation of the production line.
Deliver, shipping and serving
We analyze markets and forecast trends for you. We arrange visits and inspections for enterprises. We teach theories and guide practical operations for you. We debug equipment and guide installation for free. We respond on-site within 48 hours. We guarantee equipment quality for one year and serve for life. We update industry technology and intelligence constantly. We upgrade and optimize equipment for you continuously.
FAQ
Q1: In one machine can fill for different volume?
A1:The equipment supports multiple gable-top packaging specifications, accommodating filling capacities of 200ml, 330ml, 380ml, 500ml, 750ml, 1000ml, and 2000ml. Note that each machine supports only one box base size, but the box height is flexibly adjustable. By adjusting the height, it can fill beverages of different capacities, achieving multi-capacity compatibility. Additionally, the equipment supports composite packaging materials made from different materials (e.g., paper-aluminum-plastic composite, plastic-plastic composite, etc.), and can be customized and debugged to match the packaging requirements of the customer's products.
It is also compatible with packaging materials and lids from various global manufacturers, ensuring complete compatibility.
Q2: What are the production capacities of the gusseted pouch filling machines? Is the speed adjustable?
A2: Our gable top carton filling machines come in multiple models with production capacities ranging from 500 to 6000 cartons per hour. Equipment can be customized based on clients' production requirements and filling contents. Additionally, the machines support one-touch switching of filling volumes. Within the capacity range of the selected model, filling speed can be flexibly adjusted to accommodate different production rhythms.
