Product introduction
The whiskey carton filling machine is a fully automatic integrated equipment developed specifically for spirits such as whiskey, integrating automatic carton forming, quantitative filling, sterile sealing, cutting and sealing, and finished product output. Made of food-grade materials and equipped with an intelligent control system, it adapts to various specifications of liquid whiskey carton packaging. The fully automatic operation effectively avoids liquor pollution and filling errors, meets the needs of large-scale and standardized liquor production, and serves as the core special equipment for the whiskey carton packaging production line.
product Parameter(specification)
This special equipment is designed for batch filling production of liquid materials, meeting the whole machine hygiene standards. Except for high-rigidity support parts, all components are made of food-grade stainless steel with special surface treatment to meet the clean production requirements of the food industry. The equipment has stable mass production efficiency with an hourly output of 3000 boxes under standard working conditions, adapting to the production of products with different capacities. It is compatible with four square packaging boxes with bottom specifications of 57×57mm, 70×70mm, 83×83mm and 95×95mm. Only one specification can be selected during operation, and simultaneous operation of multiple specifications is not allowed. The filling capacity corresponds to the box one by one to form a complete capacity gradient: 57×57mm box for 250-500ml small-capacity filling, 70×70mm for 500-1000ml and 83×83mm for 1000-1500ml medium-capacity filling, 95×95mm for 1500-2000ml large-capacity filling.The equipment can switch between sealed and open modes according to production needs, supporting capping of 26-36mm lids with one fixed operation mode for single production. The whole process is room-temperature filling without temperature adjustment, suitable for most liquid materials.
The total power is 25KW with industrial three-phase power supply, ensuring stable operation and controllable energy consumption. The shelf life of finished products is inconsistent, determined by product category and manufacturing process. The supporting production conditions are clear: compressed air needs pressure of 1.0-1.4Mpa and flow rate of 1.4-2m³/min with clean, oil-free and dust-free air source; cooling water needs continuous supply of ≥40L/min flow rate and 30℃ constant temperature water. The equipment dimension is 4m×1.4m×2.8m with a weight of 3500KG, convenient for workshop layout planning. The installation conditions are simple, compatible with cement, tile and plastic industrial floors without corner plastering. The exclusive filling enhancement technology effectively solves the problem of liquid foaming and splashing during filling and ensures the stability of batch production.
product feature and application
It supports customized adjustment for whiskey carton packaging of various sizes and shapes with one-click parameter switching, convenient debugging and wide compatibility. The machine runs stably with low failure rate, suitable for small and medium distilleries and large-scale production lines.This machine is widely applied in whiskey distilleries, spirits production enterprises, liquor deep processing factories, beverage packaging processing plants and other scenarios.
product details
Complete procedures for making finished roof boxes: bottom pre-forming, bottom heating shaping, bottom sealing forming, ultrasonic film fitting, top pre-forming, material filling and filling, top sealing shaping, product date marking and printing, and finished product packaging. The production process is automatically controlled by computer programs throughout the whole process without multi-person operation, and only one operator is equipped to meet mass production needs.
product qualification
This whiskey carton filling machine strictly complies with the production specifications of the food and beverage industry and liquor safety processing standards. The core accessories are high-quality branded parts, ensuring stable overall operation, high filling accuracy and excellent sterile protection performance. Verified by mass production tests in multiple scenarios, the machine can operate continuously and stably for a long time, effectively reducing product loss and improving packaging yield, helping enterprises realize automatic, intelligent and standardized production. With the advantages of high adaptability, low failure rate and high cost performance, it has been widely matched with the production lines of many domestic and foreign liquor manufacturers. Featuring stable performance and reliable reputation, it fully guarantees the production quality and efficiency of boxed whiskey products.
Deliver, shipping and serving
The Party shall provide the customer with professional market trend forecasting and operational profit analysis services.
The Party shall be responsible for organizing and implementing field visit and inspection work for relevant industrial enterprises.
The Party shall supply comprehensive training services covering professional theoretical knowledge and practical operation skills.
The Party shall provide free on-site equipment installation guidance and commissioning services; overseas on-site debugging shall be performed in accordance with the formal agreements of both parties.
The Party shall launch a 48-hour on-site rapid service response mechanism.
All equipment products shall enjoy one-year full machine warranty and lifelong continuous after-sales service.
The Party shall continuously sort out and provide industry-related technical materials and market intelligence information.
The Party shall provide subsequent technical services for customer equipment update, transformation and performance improvement.
FAQ
Q: What after-sales services does your company provide after purchasing the equipment?
A: We provide comprehensive after-sales service guarantees:
①Free on-site installation and commissioning (for domestic customers). For international customers requiring on-site installation, the buyer shall cover round-trip airfare, accommodation, visa fees for our technicians, plus a daily service fee of $150 USD.
②Professional operator training to ensure staff master equipment operation and basic maintenance.
③One-year equipment warranty covering free replacement of non-human-damaged parts and complimentary repairs;
④24/7 service hotline for prompt maintenance requests, with on-site technicians arriving within 24 hours for nearby areas and 48 hours for remote regions;
⑤Long-term supply of wear-and-tear parts to ensure sustained equipment stability.
