Product introduction
The olive oil filling machine is a professional filling equipment specially developed for olive oil, extra virgin olive oil and other grease liquids, suitable for the filling operation of medium and low viscosity edible oils. Adopting piston metering, servo quantitative control and anti-drip filling technology, the machine is compatible with various packaging containers. The whole machine is made of food-grade stainless steel, which complies with food production hygiene standards. It effectively solves the industry pain points of easy foaming, dripping and inaccurate metering during olive oil filling, and serves as the core equipment for standardized production of olive oil processing, grain and oil food enterprises.
product Parameter(specification)
This special equipment is designed for batch filling production of liquid materials, meeting the whole machine hygiene standards. Except for high-rigidity support parts, all components are made of food-grade stainless steel with special surface treatment to meet the clean production requirements of the food industry. The equipment has stable mass production efficiency with an hourly output of 3000 boxes under standard working conditions, adapting to the production of products with different capacities. It is compatible with four square packaging boxes with bottom specifications of 57×57mm, 70×70mm, 83×83mm and 95×95mm. Only one specification can be selected during operation, and simultaneous operation of multiple specifications is not allowed.
The filling capacity corresponds to the box one by one to form a complete capacity gradient: 57×57mm box for 250-500ml small-capacity filling, 70×70mm for 500-1000ml and 83×83mm for 1000-1500ml medium-capacity filling, 95×95mm for 1500-2000ml large-capacity filling. The equipment can switch between sealed and open modes according to production needs, supporting capping of 26-36mm lids with one fixed operation mode for single production. The whole process is room-temperature filling without temperature adjustment, suitable for most liquid materials. The total power is 25KW with industrial three-phase power supply, ensuring stable operation and controllable energy consumption. The shelf life of finished products is inconsistent, determined by product category and manufacturing process. The supporting production conditions are clear: compressed air needs pressure of 1.0-1.4Mpa and flow rate of 1.4-2m³/min with clean, oil-free and dust-free air source; cooling water needs continuous supply of ≥40L/min flow rate and 30℃ constant temperature water. The equipment dimension is 4m×1.4m×2.8m with a weight of 3500KG, convenient for workshop layout planning. The installation conditions are simple, compatible with cement, tile and plastic industrial floors without corner plastering. The exclusive filling enhancement technology effectively solves the problem of liquid foaming and splashing during filling and ensures the stability of batch production.
product feature and application
Fitted with special anti-drip filling nozzles, it effectively avoids oil foaming and bottle overflow. No residual oil drips from the filling port to keep the equipment and bottles clean.This equipment is widely used in grain and oil food processing factories, olive oil deep-processing enterprises, high-end condiment production workshops, supermarket bottled oil supply chain factories and other scenarios. It is suitable for the filling of all categories of olive oil including extra virgin olive oil, refined olive oil and pomace olive oil, and also compatible with the production of high-end niche edible oils such as camellia oil, flaxseed oil and avocado oil
product details
Nine major processes are carried out in sequence in roof box production: bottom pre-forming process, bottom heating shaping, bottom sealing forming, ultrasonic covering treatment, top pre-forming processing, material loading and filling, top sealing forming, production date spraying, and finished product sorting and packaging. The operation of the whole production line is accurately controlled by computer throughout the whole process with high automation, and only one operator is required for full-line operation and maintenance.
product qualification
This olive oil filling machine strictly complies with food machinery safety production standards, and its overall material, production technology and filling accuracy have passed industry quality inspection certifications. Meanwhile, the equipment supports customized production capacity, specifications and assembly line configurations according to demands to meet the personalized production needs of different enterprises. With stable operation and high energy efficiency, thousands of grain and oil food enterprises realize automatic, standardized and clean oil filling production, winning wide industry recognition and good reputation.
Deliver, shipping and serving
Undertake market forecast research and profit benefit analysis work for customer enterprises.
Be responsible for the organization and implementation of field visit and inspection affairs of relevant industrial enterprises.
Provide standardized and comprehensive training services covering professional theory and practical operation.
Render free on-site installation guidance and equipment debugging services, and overseas service contents shall be performed in accordance with bilateral contractual agreements.
Implement a 48-hour on-site service response system to solve customer problems efficiently.
Provide one-year full machine quality warranty and lifelong continuous after-sales service for all equipment products.
Regularly sort out and deliver industry technical documents and market dynamic intelligence.
Launch targeted follow-up service solutions for equipment update, transformation and performance improvement.
FAQ
Q1: What are the differences between gable top carton and Tetra Pak?
A1: Gable top carton uses sheet-based packaging material. A single machine can fill multiple capacities, which are adjustable. Production speeds range from low to high, accommodating various types of contents.
Tetra Pak uses roll-based packaging material. A single machine can only fill one fixed capacity, which is non-adjustable. These machines lack low-output options, are expensive, and incur high maintenance costs.
Q2: What preliminary preparations are required for equipment installation?
A2: The following conditions must be prepared for equipment installation:
①Site Requirements: Provide a level, dry, and well-ventilated site. The required area depends on the equipment model, typically requiring 30-100㎡ (including space for operation and maintenance).
②Installation Requirements: Water, electricity, and compressed air connections are required for operation. Customers must provide their own air compressor.
