Product introduction
This full-automatic packaging unit integrates carton forming, quantitative filling, sealing and finished discharging, divided into ambient and aseptic versions. Compatible with gable-top and brick paper containers, it fills juice, milk, sauces, plant drinks and other liquid & semi-liquid materials. With PLC intelligent control, it delivers stable metering and easy size switching, widely applied in clean production lines for food & beverage, daily chemical and nutrient solution sectors.
product Parameter(specification)
This special equipment is suitable for the filling production of liquid materials such as food and beverages. The whole machine meets safety material standards. Except for the high-rigidity support structure, all parts are made of food-grade stainless steel with special surface treatment, adapting to the environment of clean production workshops. The equipment has stable mass production capacity, completing 3000 filling boxes per hour. One of the four box specifications (57×57mm, 70×70mm, 83×83mm, 95×95mm) can be selected according to production needs, and simultaneous multi-specification production is not supported. Each box specification matches an exclusive filling range to accurately meet production needs of different capacities: the small-capacity 57×57mm box for 250-500ml, medium-capacity 70×70mm and 83×83mm boxes for 500-1000ml and 1000-1500ml respectively, and large-capacity 95×95mm box for 1500-2000ml.
It flexibly adapts to sealed and open production needs, supporting capping and non-capping operations for 26-36mm lids, with dual functions and single mode selection for each operation. Adopting room-temperature filling process, the equipment is suitable for most liquid materials without temperature control equipment. The operating power is 25KW, running stably with three-phase industrial power supply. The shelf life of finished products is not fixed, which is mainly determined by material category and production process. The supporting production conditions are clear: clean compressed air needs pressure of 1.0-1.4Mpa and flow rate of 1.4-2m³/min (oil-free and dust-free); cooling water needs continuous supply with flow rate ≥40L/min and constant temperature of 30℃. The equipment covers an area of 4m×1.4m×2.8m with a total weight of 3500KG, convenient for workshop layout. It has low installation threshold, which can be installed on conventional industrial cement, tile and plastic floors without additional corner treatment. The exclusive filling enhancement function effectively avoids liquid foaming and splashing during filling, reducing material loss and equipment pollution.
product feature and application
Fast mold switching for multi-size cartons without major program revision; multi-function machine cuts procurement cost.
Aseptic version owns multiple utility patents; sterilization and filling tech pass authoritative tests with indicators above industry average.
Full-process computer automatic control, only one operator required with minimal labor input.
Application: Juice, milk, compound sauces, plant drinks, daily chemical nutrient liquid in gable-top & brick cartons.
product details
- Bottom pre-shaping
- Bottom heating forming
- Bottom sealing
- Ultrasonic lamination
- Top pre-forming
- Quantitative filling
- Top sealing shaping
- Date coding
- Finished sorting & storage
product qualification
Core aseptic filling structure owns multiple utility patents. Filling precision, aseptic performance and continuous stability pass industrial tests, meeting export standards with international certifications for global sales.
Deliver, shipping and serving
Custom market forecast & profit data analysis for clients
On-site enterprise visits & standardized inspection arrangement
Integrated vocational training of theory & operation practice
Free on-site installation & commissioning; overseas service under bilateral agreements
48-hour rapid on-site fault response system
1-year full machine warranty & lifelong technical support
Continuous update of cutting-edge industrial technology information
Long-term follow-up for equipment technical transformation & performance upgrade
FAQ
Q1: What are the advantages of the core technologies used in the equipment?
A1: The core technologies offer significant advantages:
① High-precision filling valves ensure filling accuracy with an error margin ≤±1%, guaranteeing uniform product volume per pouch;
② An intelligent control system enables simple and convenient operation, allowing real-time monitoring of production parameters for timely adjustments and maintenance.
Q2:How should equipment undergo routine maintenance?
A2: Daily equipment maintenance is relatively low in difficulty and simple to operate. Key daily maintenance points:
①After each production run, promptly clean filling valves, material pipelines, and other components in contact with materials to prevent bacterial growth from residue;
②Regularly inspect transmission components (e.g., chains, gears) and add lubricant as needed to ensure smooth operation;
③Periodically check seal wear and replace immediately if leaks or damage are detected;
④Maintain clean equipment surfaces to prevent dust and debris accumulation;
⑤Strictly follow the equipment operation manual to prevent damage from improper use.
